Color Laminated Glass

No.LYD-CLGG
Color Laminated Glass
Glass thick
3mm,4mm,5mm,6mm,8mm,10mm,12mm
Edge processing
Seamed Edge, Round edge ,Flat edge
Pvb Thick
0.3mm,0.38mm,0.76mm,1.14mm,1.52mm
Pvb Color
Colorless, white, milk white, blue, green, gray, bronze, red, etc.
Min Size
100mm*100mm
Max Size
3660mm*2600mm
Port of Loading
Xingang port
Package
Plywood Crates
  • Color Laminated Glass
  • Color Laminated Glass
  • Color Laminated Glass
  • Color Laminated Glass

Description

Product Overview

Colored laminated glass is a safety glass built from two or more glass sheets bonded around a colored polyvinyl butyral (PVB) interlayer. The color sits inside the laminate rather than on the face of the glass, so the panel keeps its gloss, its clean edge and its ability to stay in one piece when something hits it hard.

Most projects arrive here for one of three reasons: a partition that has to work as privacy glass without turning a room into a box, a facade that needs to cut glare and solar gain without going dark, or an interior that has to match a color scheme and still satisfy the safety requirement of the opening. One panel does all three, which is why architects, glazing contractors and fabricators specify this build instead of combining clear laminated glass with applied film, blinds or back-painted panels.

LYD GLASS is a laminated glass manufacturer based in Qinhuangdao, producing to drawing rather than to a stock list. Each panel is custom laminated glass, made in the thickness, color and edge finish the project calls for, and every order is quoted against the sizes and quantities you send.

Color laminated glass earns its place on a project when one panel has to do the work of several: hold together after impact, carry a color the design can use, and take the edge off a view or a noise problem at the same time. It suits facades, partitions, balustrades, shopfronts and furniture, and it can sit alongside clear or frosted panels from the same production run so an interior keeps one visual language. Where a project needs maximum post-breakage strength and nothing else, a structural laminate is the simpler answer. Where it needs a single sheet of color and no safety function, tinted float glass will do. This build is the one to specify when the color is part of the design and the opening still has to behave like safety glass. Working as laminated glass manufacturers, we quote each project against the sizes, thicknesses, colors and edge work it actually needs rather than around a fixed range. Send the drawing set and the quantity, and the build follows from there.

Build and Composition

  • Glass plies in the thickness the job needs. The full range is set out in the specification, and a laminate can pair two different thicknesses, so the panel is matched to its span and its load rather than to whatever laminated glass suppliers happen to have on the shelf.
  • A colored PVB interlayer through the body. Polyvinyl butyral carries the pigment across the full face, and its own gauge is specified separately from the glass, which keeps tint depth and panel strength as two decisions instead of one.
  • Bonded into a single sheet. Heat and pressure marry glass and interlayer until the layers behave as one panel: no adhesive line to see through, no film edge to collect dirt, no visible border where the color stops.
  • The same color from both faces. Because the tint sits inside the laminate, the panel reads the same from the street and from the room, and it keeps its depth at an angle rather than flattening out the way a surface coating does.
  • Edge work after lamination. Laminated glass panels are cut and finished to the profile you order, so they go into the frame without further dressing on site.
  • Tempered or heat-strengthened plies on request. We run our own tempering line, so if the specification calls for safety glass either side of the interlayer, say so at enquiry and the build is set up that way.
  • Consistent color across a run. This is where laminated glass manufacturers earn their keep: a facade ordered in stages has to match itself, so panels produced months apart are made to the same interlayer reference.

Color and Transparency Range

Color is the reason most buyers choose this build, and the range is wide enough to carry a scheme rather than just tint a window. Standard interlayers run through colorless, white, milk white, blue, green, gray, bronze and red, with other shades available to match a reference you supply. Depth varies as much as hue: a pale blue still reads as glass and keeps a room bright, while a deep indigo or a saturated green turns the panel almost opaque and becomes a surface in its own right. The face stays glossy, so the color shifts slightly with the light through the day, which is why a full-size panel tells you more than a small chip when the wall is large.

Transparency is set independently of color. A transparent interlayer gives a clear, jewel-like tint you can see through; a translucent or frosted build diffuses the view while still passing daylight and is the usual route to privacy glass; an opaque build closes the sightline completely. Because all three are made the same way, one elevation can mix them, clear at eye level and frosted above, without a change of supplier or glazing system.

That built-in color is the practical difference between colored laminated glass and a tinted film applied after the fact. There is nothing to peel, bubble or leave a border, and the shade does not wear thin where the panel is handled most.

Safety and Post-Breakage Behavior

Laminated glass panels do not fall apart. When a panel is struck hard enough to crack, the fragments stay bonded to the interlayer, so the opening stays closed and broken glass does not reach the floor or the people below. For a balustrade, an overhead skylight or a door taking daily traffic, that behavior is the reason the build gets specified at all.

Colored laminated glass does not weaken the safety function. A colored panel behaves exactly like a clear one of the same build — same glass, same bonding, same post-breakage retention — you simply get less light and more privacy in the bargain.

Forced entry is slowed rather than invited. Cutting through a laminated panel takes sustained effort and repeated impacts, which is why ground-floor windows, shopfronts and display cases are often upgraded to safety glass. Colored laminates do that work without looking like security glass, so a commercial frontage keeps its design intent.

A failure is easy to see. A cracked panel usually shows a spider pattern or a network of cracks held in place, which makes it simple to identify and schedule as a single replacement unit. Keep the original drawing with the project file so a replacement can be produced to the same interlayer reference.

If the opening is checked against a particular safety code, tell us which one at enquiry stage and we will confirm the build that applies before the order is placed.

Solar, UV and Energy Performance

  • UV filtration. The colored PVB interlayer absorbs most ultraviolet light before it reaches the room, which is the practical protection for timber floors, upholstery, artwork and merchandise that would otherwise fade.
  • Glare control. A deeper color cuts the visible light coming through, so screens stop reflecting in a west-facing office and staff stop working around half-closed blinds.
  • Solar gain. Color reduces the heat passing through the glass, easing the load on air conditioning in glazed lobbies and sunlit rooms.
  • Daylight retained. A mid-tone panel still passes useful daylight; the room darkens, but it does not go dim, which is the balance opaque blinds cannot strike.
  • Combined builds. Where thermal performance drives the specification, the panel can form one of the panes in an insulating unit, so color, safety and insulation come from the same opening.
  • In laminated glass windows, the benefit shows up as less fading and less glare rather than as a single headline number, so specify the outcome you want and let the build follow.
  • Project targets. Exact performance depends on glass thickness, interlayer and the size of the opening; if the project has a figure to hit, send it with the enquiry and we will confirm what the build can do.

Acoustic Comfort and Privacy

The interlayer that carries the color also damps sound. Laminated glass panels cut traffic noise, conversation and equipment hum more effectively than a single sheet of the same overall thickness, because the soft core breaks the path that vibration travels along. A thicker interlayer pushes that further, which is why hotels, clinics and offices on busy streets tend to specify a laminate rather than monolithic glazing.

Privacy glass is where color does the work acoustics cannot do. A milk white or frosted interlayer gives a bright, evenly lit room with no view in or out. A deep blue or green brings the same effect with more character. A pale tint takes the edge off a sightline without pretending to hide anything. That range lets one specification cover a meeting room that needs full privacy, a consulting room that needs daylight, and a reception that wants a color statement.

The two benefits stack in the same panel. A hotel facing a main road gets the traffic noise down and stops guests being overlooked at the same time — difficult to achieve with blinds or film alone.

Privacy level is a design decision, not a fixed property. Tell us how much you want to see through the panel and what it has to hide, and we will point to the interlayer and tone that do it. If acoustic performance is specified as a target, include the figure with the enquiry so the build can be checked against it.

Architectural Glazing Applications

  • Curtain walls and facades. Color banding, spandrel panels and full-height glazing where the elevation needs a consistent tone across hundreds of square meters.
  • Laminated glass windows and doors. Street-facing openings that need safety glazing, glare control and a color matching the rest of the elevation.
  • Skylights and overhead glazing. The interlayer holds a broken pane in the frame, which matters most when the glass is above people's heads.
  • Balustrades and glass railings. Structural laminates with a tinted edge give a guard that reads as a design element rather than a barrier.
  • Shopfronts and entrances. Color announces the brand at the threshold while the laminate handles impact and attempted entry.
  • Stair screens and lift lobbies. Tall panels where the color runs the full height without a joint interrupting it.
  • Laminated windows in stairwells and service areas, where daylight is welcome but a clear view is not.
  • Canopies and walkway roofs, where overhead safety and solar control are asked of the same panel.
  • Inside a building, the same panel solves problems that otherwise take several materials. A run of colored glass splits an open-plan office into a meeting room and a corridor while both sides keep their daylight, and because the color is in the laminate, both sides see the same shade. Reception walls and lift lobbies use a deeper interlayer the way a painted wall would be used, except that the surface reflects and the room stays bright. Furniture is a steady part of this work. Tabletops, shelving, cabinet fronts and low tables are usually built on mid-range plies with a colored interlayer, thin enough to keep the piece manageable and thick enough for daily use. A colored shelf or tabletop gives a room its accent without another finish to maintain. Shower enclosures are the most practical interior use. A milk white or frosted laminate gives privacy and still lets light into the bathroom, the panel holds together if it is struck, and the color does not depend on a coating that can lift at the edges. Flag wet-area installations when you send the enquiry so the edge detail and fixings are planned for moisture. Commercial displays and showcases use the material to frame rather than to hide: a colored back panel or shelf edge sets off the product, and the glass takes the knocks of a busy aisle. Shop-in-shop units and exhibition stands often order the same build in small panels, which is where ordering below full sheet size comes into its own. Colored panels also work as wayfinding — a color-coded department, a tinted balustrade around an atrium, a branded screen at an entrance. It is the same product across all of these, specified once and repeated.

Specifications

The exact gauges sit in the specification above; what matters here is which end of the range a job belongs at. - The middle gauges for partitions, doors, shower screens and shopfront displays — the common ground for architectural interiors. - The heaviest plies where a panel spans further, sits in a balustrade, or takes regular knocks in a public area. - The thinnest interlayer as the everyday starting point: enough for most decorative and interior panels. - One gauge up and beyond where the panel must hold together longer after impact, or where sound reduction is part of the brief. - The two heaviest interlayers for structural and overhead work, where what happens after breakage matters most. - Long panels. If a design runs past the maximum sheet size, split it into modules on the mullions; a joint set on a frame line reads better than a panel pushed to the limit of the process. - Mixed specification. Thickness, interlayer and color are quoted together as custom laminated glass, so tell us the priority — budget, weight, acoustic or post-breakage performance — and the build follows from it. - Cut to drawing. Panels are produced to the dimensions on your drawing rather than to a stock module, so an opening does not have to be redesigned around a catalogue. - Seamed edge for a soft, economical finish on panels that will be framed or where the edge is rarely touched. - Round edge for exposed edges on partitions and balustrades, where a hand may run along the glass and a polished profile matters. - Flat edge where panels butt together or sit in a clamp fixing, so the joint line stays tight and even. - Cut-outs and holes. Water-jet cut-outs for hinges, handles, sockets and fixings, drilled to your drawing before toughening or lamination as the build requires. - Marking. Logos and permanent marks applied to your specification for branded interiors and repeat commercial rollouts. - Mixed packages. One order can carry several colors, thicknesses and edge profiles, which keeps a project package on one delivery and one color reference. - OEM and ODM work is accepted where a brand needs its own drawing set, specification and packing marks. Working with laminated glass suppliers usually means choosing from a catalogue; here the drawing drives the panel. - What to send. PDF or DWG drawings, panel sizes, color reference, edge profile, quantity and the date you need the glass on site.

Installation Requirements

  1. Measure the finished opening, not the structural one, and check each panel against the drawing before it leaves the crate.
  2. Plan the lift before the panel is out of the packaging; large laminates need suction lifters and two people at minimum, and heavy panels need mechanical handling.
  3. Store panels on edge on a padded rack in a dry area, never flat on a floor and never leaning against a wall without support.
  4. Set the panel on setting blocks at the quarter points so the glass is not resting on its own edge inside the frame.
  5. Keep the panel edge clear of standing water and follow the drainage detail in the frame design; the interlayer is exposed at the edge and does not want to sit in a puddle.
  6. Use glazing sealants and gaskets that are compatible with laminated glass, and check any unfamiliar sealant with us before it goes near the edge.
  7. Align and fix the frame before final sealing, so the panel is not holding the frame's errors in place.
  8. Leave protective film and site tape on only as long as the manufacturer allows, and remove them before handover.
  9. Clean color laminated glass the way you would clean any quality glass: warm water with a little mild detergent, a soft cloth or squeegee, then a rinse and a dry with a non-abrasive cloth. Abrasive pads, scrapers and aggressive solvents are the usual cause of damage — they dull the surface and can mark the interlayer if they reach an exposed edge. Water is the thing to watch. Standing water at the bottom edge of a panel is what shortens the life of a laminate, so keep frame drainage clear and wipe up pooling after cleaning. On laminated windows that face the weather, the glazing detail should protect the edge rather than leave it exposed, and the seal is worth checking during routine maintenance. Color stability varies with the shade and with exposure. Some colors shift over years of direct sun, deeper shades generally hold longer than pale ones, and a panel in a shaded courtyard will look the same in a decade while one on a west facade may not. If a project faces long sun exposure, tell us at enquiry and we will advise on the shade and build; checking a full-size panel in the actual light is more reliable than judging from a small sample. Inspect the edges when you clean. A chipped edge or a lifted seal is worth reporting early, because a small repair or a planned replacement costs far less than a panel that fails in service. Keep spare panels on edge, on a padded rack, in a dry place. Stacked flat on a floor, a heavy laminate picks up scratches and point loads that only show once it is installed.

Ordering and Delivery

  • Send the drawings. Panel sizes, glass thickness, PVB color and thickness, edge finish, quantity and the date you need the glass on site.
  • Quotation basis. Each panel is priced on build, size, edge work and quantity, so a change of interlayer or edge profile changes the figure — send the full package in one go for a comparable price.
  • Nothing is cut until the drawing is approved. As a laminated glass manufacturer rather than a stockist, we work from your approved drawing, and a loading plan is confirmed with you before production starts.
  • Packing. Plywood crates or A-Steel racks, chosen to suit the panel size and the shipping method.
  • Shipping. Export packing as standard for sea freight.
  • Port of loading. Xingang port.
  • Lead time and payment terms. Confirm both with your sales contact so production and site programme are working to the same date.
  • Export documents. Tell us what your broker needs and we will confirm which paperwork can be issued with the shipment.

Scale & Supply Capability

LYD GLASS manufactures and exports glass for project buyers, fabricators and contractors who prefer to buy direct from a production source. Everything we supply is made to order: send drawings, sizes, quantities and finishing requirements, and we return a factory quotation against them. Panels are packed for export in plywood crates or A-Steel racks and protected for sea freight. We work to your delivery schedule, support repeat orders and answer specification questions before production starts. Send your requirements for a quote.

FAQ

Q1. What materials are used in color laminated glass?

Two or more glass sheets bonded around a colored polyvinyl butyral (PVB) interlayer. The PVB carries the color and also does the safety, UV and acoustic work, while the glass itself can be clear or body-tinted. Float glass and PVB come from established suppliers, and as laminated glass manufacturers we can confirm the exact brand and interlayer grade for your order on request.

Q2. Can I order custom laminated glass in my own sizes and colors?

Yes. Size, glass thickness, interlayer thickness, color and edge finish are all made to order, so the panel is built to your drawing rather than chosen from a stock range. Send the drawing with a color reference and the edge profile you want, and we will confirm the closest match before production. Working with laminated glass suppliers usually means picking from a list — here the list is only the starting point.

Q3. How much light does a colored interlayer let through?

It depends on the shade and on whether you choose a transparent, translucent or opaque interlayer. A pale tint keeps a room bright, a mid-tone cuts glare while still passing daylight, and a deep shade or an opaque build closes the sightline. We do not publish a transmission figure per shade because it moves with interlayer and glass thickness; if the project has a daylight target, send it and we will advise on the build that meets it.

Q4. What happens to color laminated glass if it breaks?

The interlayer holds the fragments, so the opening stays closed and the broken glass does not scatter. The crack pattern makes it clear which panel has failed, and because each panel is produced to drawing, the replacement is made to the same specification and interlayer reference. That is the practical advantage of laminated glass over a single tinted sheet in doors, overhead glazing and balustrades.

Q5. Can color laminated glass be used in laminated glass windows and doors?

Yes. It glazes into standard window and door frames like any laminate, and it can also form one of the panes in an insulating unit where thermal performance matters. Check the frame's drainage and its maximum panel weight with the frame supplier, and make sure the glazing detail protects the panel edge. For laminated windows on exposed elevations, that edge protection is what keeps the panel looking right for years.

Q6. How does it differ from tinted float glass?

Tinted float glass is a single sheet with the color in the glass body, and it does not hold together when it breaks. Color laminated glass puts the color in an interlayer between two sheets, so you get the shade plus post-breakage retention, UV filtration and sound dampening from the same panel. Tinted float is the economical choice for a purely decorative pane; the laminate is the one to specify where the opening is above head height, in a door, or in a balustrade.
