| 12mm Clear Tempered Glass | |
| Thick | 12mm |
| Edge processing | Flat edge and Polished |
| Standard | CE EN 12150-2:2004 |
| ANSI Z97.1-2015(R2020) | |
| CAN/CGSB-12.1-2022 | |
| CPSC 16 CFR 1201-2024 | |
| Min Size | 100mm*100mm |
| Max Size | 3660mm*2440mm |
| Port of Loading | Xingang port |
| Package | Plywood Crates,A-Steel Rack etc |
12mm tempered glass doors are doors made of glass that has been heat-treated to increase its strength and safety, with a thickness of 12 millimeters. These doors are popular in various architectural and design contexts due to their modern appearance and tough characteristics. Here’s an overview of 12mm tempered glass doors, including their benefits, applications, and considerations.
Strength and Durability:
Safety:
Thermal Resistance:
Aesthetic Appeal:
Minimal Maintenance:
Natural Light:
Space Optimization:
Versatile Design Options:
Accessibility:
Security:
Shower Doors:
Interior Doors:
Exterior Doors:
Commercial Spaces:
Closet Doors:
Cost:
Installation:
Framing:
Weight:
12mm tempered glass doors are a fantastic choice for those looking to combine safety, strength, and aesthetic appeal. They are versatile enough to be used in various settings from residential to commercial spaces. If you have specific combinations, designs, or projects in mind involving tempered glass doors, feel free to share, and I can provide more tailored advice!
| Specification | Detail |
|---|---|
| Glass type | Clear tempered (toughened) safety glass |
| Appearance | Clear, with a faint green edge tint |
| Safety standards | CE EN 12150-2:2004; ANSI Z97.1-2015(R2020); CAN/CGSB-12.1-2022; CPSC 16 CFR 1201-2024 |
| Panel build | Door leaf, side light or fixed glazed panel |
| Model reference | LYD-CTGD12 |
Toughening is a heat treatment rather than a coating: the glass is heated and then cooled quickly, locking its outer surfaces into compression. That is the strength behind a leaf that shrugs off slamming, leaning and daily wear where ordinary annealed glass would crack. The same treatment lets the panel cope with the temperature swings of a sunny shopfront or a steam-filled bathroom without stressing. Because the whole thickness is toughened and not just the surface, the leaf counts as custom safety glass in any position on the door.
LYD GLASS supplies architectural glass to project and wholesale buyers, covering tempered, laminated, mirror, insulated and decorative glass from one source. Our tempered range runs from 3 mm to 19 mm in clear, ultra-clear low-iron, green and bronze/brown, with seamed, round, flat or polished edges produced to your drawings and sheet sizes up to 3660 mm x 2440 mm. Production follows CE EN 12150-2:2004, ANSI Z97.1-2015(R2020), CAN/CGSB-12.1-2022 and CPSC 16 CFR 1201-2024, and orders ship from Xingang in plywood crates or A-steel racks.
Yes — width and height follow your door schedule, so a non-standard opening is routine. Send the opening dimensions, the quantity, the edge finish and the fittings you plan to use, and we will confirm the panel sizes with you. Custom tempered glass panels are produced for the frame you have rather than a stock size, so the leaf arrives ready for the opening on site.
Toughened glass releases as small, blunt fragments instead of long sharp shards, which is one reason this leaf counts as custom safety glass. In practice, damage starts at an edge chip or a direct hit on the face during handling or installation rather than from everyday use, so keep the edge protection in place until the panel is fixed. If a leaf is ever damaged, the original panel dimensions let us produce a matching replacement.
Yes. Hinge recesses, pivot points, lock cases and handle holes are cut into the annealed sheet first, and toughening comes last, so every opening is set precisely for the hardware you specify. Send your hardware schedule with the door sizes and we will confirm each position on the shop drawing before your custom made tempered glass is toughened.
Clear is the standard build for these door leaves, and frosted or tinted finishes can be produced where privacy or glare control matters. Those custom tempered glass panels keep the same door dimensions and edge treatment, so your hardware schedule does not change. Send the tone you want with the drawing and we will confirm the panel build.
The 12 mm leaf is the heavier-duty choice: it holds a flatter face over tall or wide openings and takes frequent contact well. A 10 mm panel is lighter and is often enough for quieter interior doors. As a tempered glass supplier we produce both, so tell us the opening size, the traffic and the fittings you plan to use and we will confirm which thickness suits the door.
Wipe the panel with a soft cloth and a standard non-abrasive glass cleaner; the smooth surface releases everyday marks without special products. Avoid scouring pads, blades and abrasive powders, which can scratch the face or chip an edge. Check the hinges or pivot from time to time and keep the door swinging freely so the fittings are not strained.
