10mm Sliding Tempered Glass Door

No.LYD-STGD10
10mm Clear Tempered Glass
Thick
10mm
Edge processing
Flat edge and Polished
Standard
CE EN 12150-2:2004
ANSI Z97.1-2015(R2020)
CAN/CGSB-12.1-2022
CPSC 16 CFR 1201-2024
Min Size
100mm*100mm
Max Size
3660mm*2440mm
Port of Loading
Xingang port
Package
Plywood Crates,A-Steel Rack etc
  • 10mm Sliding Tempered Glass Door
  • 10mm Sliding Tempered Glass Door
  • 10mm Sliding Tempered Glass Door
  • 10mm Sliding Tempered Glass Door

Description

10mm sliding tempered glass door is a popular choice for both residential and commercial applications due to its combination of strength, aesthetic appeal, and functionality. Here’s an overview of its features, advantages, applications, and considerations.

Features of a 10mm Sliding Tempered Glass Door

  1. Thickness:

    • The 10mm thickness provides a robust structure compared to thinner glass options. This thickness is considered ideal for security and durability.
  2. Tempered Glass:

    • The glass is tempered, meaning it has undergone a heating and cooling process that increases its strength and allows it to withstand greater pressure and thermal fluctuations.
  3. Sliding Mechanism:

    • These doors typically feature a track system that allows them to slide open and closed, making them space-efficient and easy to operate.
  4. Transparency:

    • With high optical clarity, tempered glass allows for excellent natural light transmission, enhancing the ambiance of any space.

Advantages of 10mm Sliding Tempered Glass Doors

  1. Strength and Durability:

    • The 10mm tempered glass offers significant impact resistance and is less likely to shatter compared to thinner glass options. It can support more weight and withstand better environmental factors.
  2. Safety:

    • When broken, tempered glass crumbles into small, blunt pieces, minimizing the risk of injury.
  3. Minimal Maintenance:

    • These doors are typically easy to clean, requiring only regular maintenance to keep them looking clear and pristine.
  4. Aesthetic Appeal:

    • A sliding tempered glass door provides a modern, sleek look, enhancing the appearance of homes or businesses. It can create a sense of openness, connecting indoor and outdoor spaces.
  5. Energy Efficiency:

    • With the right frame and insulation, tempered glass doors can help to retain heat or cool air, contributing to energy efficiency in a building.
  6. Space-Saving:

    • Sliding doors take up less space compared to traditional swinging doors, making them an excellent option for small areas.
  7. Customizable Options:

    • 10mm tempered glass doors can often be customized in various configurations, sizes, and finishes, including clear, frosted, tinted, or patterned glass.

Common Applications

  1. Patio or Balcony Doors:

    • Sliding glass doors are frequently used for access to patios, balconies, and outdoor spaces, offering seamless transitions and views.
  2. Room Dividers:

    • They can serve as stylish room dividers in open-concept living spaces, allowing for flexibility in space usage.
  3. Shower Doors:

    • 10mm tempered glass is often used in frameless shower enclosures due to its strength and appealing look.
  4. Commercial Spaces:

    • Used in offices, retail stores, and other commercial buildings to create appealing entrances while allowing visibility into merchandise or internal spaces.
  5. Entry Doors:

    • They can also serve as striking front doors, creating an inviting entrance that allows for natural light.

Considerations

  1. Weight:

    • Due to its thickness, a 10mm sliding glass door can be quite heavy, and proper support and hardware are essential for smooth operation.
  2. Installation:

    • Professional installation is recommended to ensure safety and proper function, particularly with the handling of heavy glass and the installation of tracks.
  3. Cost:

    • While 10mm tempered glass doors provide many benefits, they can be more expensive upfront compared to standard doors, so it’s crucial to consider your budget.
  4. Conditioning:

    • Ensure correct handling and maintenance to protect against scratches and ensure smooth sliding functionality.
  5. Frame and Hardware:

    • The choice of frame (aluminum, wood, etc.) and hardware can affect the overall aesthetics and longevity, so select quality materials.

Conclusion

A 10mm sliding tempered glass door is an elegant and functional option that can enhance any space, providing aesthetic appeal and practicality. It is an excellent choice for those looking for a modern solution that maximizes views while maintaining safety and durability. If you have specific design preferences, installation questions, or need further details, feel free to ask!




Product Overview

A sliding tempered glass door is a single toughened leaf that runs on a track past a fixed panel or a wall. It suits both commercial and residential openings. As a tempered glass supplier we produce the leaf and leave the track, rollers, floor guide and handles to the hardware system you specify.

Specifications

ItemSpecification
ModelNo.LYD-STGD10
Glass typeClear tempered glass
Safety standard (US)ANSI Z97.1-2015(R2020)
Safety standard (US, CPSC)CPSC 16 CFR 1201-2024
Safety standard (Canada)CAN/CGSB-12.1-2022
Minimum panel size100 × 100 mm
Maximum panel size3660 × 2440 mm

Track Fit, Installation and Care

  • Top-hung tracks carry the leaf from a head rail and leave the floor line clear for sweeping; bottom-rolling systems take the weight on floor rollers, which are simpler to service but need a level sill and a straight track recess.
  • Hanger spacing matters more than most buyers expect: the rollers must sit far enough apart to hold the leaf without rocking, and those positions come from the track template — send it to us as the glass door manufacturer and the cutouts are made to suit.
  • Floor guides keep the panel tracking in line; allow enough clearance under the glass for the guide to sit clear of the finished floor. Frame choice matters too — aluminium, timber or fully frameless — because the frame you set the track into affects both the look of the opening and how long the door runs true.
  • Set the head track level and plumb before the heavy panel is lifted, lift with vacuum cups and two people as a minimum, then run the full travel, tune the bottom guide and check any soft-close unit.
  • A frameless shower enclosure uses the same glass in a different format: a tempered glass shower door panel usually swings on hinges or a pivot, so its fixing positions differ from a sliding leaf.
  • Routine care keeps the door running: keep the track and guide free of grit, wipe the glass with a non-abrasive, ammonia-free cleaner, and check the hangers if the leaf begins to drag.

Scale & Supply Capability

LYD GLASS supplies architectural glass to project and wholesale buyers, covering tempered, laminated, mirror, insulated and decorative glass from one source. Our tempered range runs from 3 mm to 19 mm in clear, ultra-clear low-iron, green and bronze/brown, with seamed, round, flat or polished edges produced to your drawings and sheet sizes up to 3660 mm x 2440 mm. Production follows CE EN 12150-2:2004, ANSI Z97.1-2015(R2020), CAN/CGSB-12.1-2022 and CPSC 16 CFR 1201-2024, and orders ship from Xingang in plywood crates or A-steel racks.

FAQ

Q1. When should a thicker door panel be used instead?

For most interior and shopfront leaves this panel has the body to stay steady in a doorway and take the knocks of daily use. If an opening is unusually tall, or the door is in constant heavy traffic, a 12 mm tempered glass door panel gives extra stiffness and weight, and hardware with a higher load rating suits it better. Send the opening sizes and we will confirm which thickness suits the job.

Q2. Can you make the panels to my own opening sizes?

Yes — we produce custom tempered glass panels to the finished opening, so the sizes you give us become the cut list for the leaf. Take the measurements once the floor, head and jambs are in place rather than from the structural opening, so the leaf fits the finished gap.

Q3. What happens if the glass breaks?

It fails safe. Tempered glass breaks into small, blunt-edged pieces rather than long shards, which is why it is specified for doors and other openings people walk through. A damaged panel crumbles into that pattern across the whole sheet instead of cracking along a single line.

Q4. Can the panel be cut or drilled on site if something does not line up?

No — once glass is toughened, its shape is locked, so it cannot be cut, drilled or ground afterwards. Every dimension, edge and opening is fixed before toughening, which is why the sizes and the hardware template have to be right when you order. As a glass door manufacturer we check that specification against your template before the glass is cut.

Q5. Can the door glass be supplied in a finish other than clear?

Yes. This is tempered glass custom size work, so the leaf is made to your opening, and the glass itself can be supplied clear, frosted, tinted or patterned to suit the interior. Clear is the usual choice for a sliding door where you want the view and the light to carry through, while frosted or tinted glass is chosen where more privacy or glare control is needed.

Q6. Will this panel suit a frameless shower enclosure?

Yes — a tempered glass shower door panel is a familiar gauge for frameless enclosures, where the glass is left almost entirely exposed. The fixing positions differ from a sliding leaf, though: shower panels usually swing on hinges or a pivot, so send the enclosure maker's panel sizes and hardware details. We cut the leaf, hinge cutouts and handle holes to suit that hardware.
